Grouped visualizations of correlation matrices

Applies ggcorrmat() across all levels of grouping.var and combines the resulting plots using combine_plots().

Usage

grouped_ggcorrmat(
  data,
  ...,
  grouping.var,
  plotgrid.args = list(),
  annotation.args = list()
)

Arguments

data

A data frame from which variables specified are to be taken.

...

Arguments passed on to ggcorrmat

cor.vars

Variables for which the correlation matrix is to be computed and visualized, specified using {tidyselect} syntax (e.g., c(var1, var2) or starts_with("Sepal")). If NULL (default), all numeric variables from data will be used.

cor.vars.names

Optional list of names to be used for cor.vars. The names should be entered in the same order.

partial

Can be TRUE for partial correlations. For Bayesian partial correlations, "full" instead of pseudo-Bayesian partial correlations (i.e., Bayesian correlation based on frequentist partialization) are returned.

matrix.type

Character, "upper" (default), "lower", or "full", to display the upper triangular, lower triangular, or full matrix, respectively.

sig.level

Significance level (Default: 0.05). If the (adjusted; see p.adjust.method) p-value is bigger than sig.level, then the corresponding correlation coefficient is regarded as insignificant and flagged as such in the plot. Ignored for type = "bayes".

pch

Decides the point shape to be used for insignificant correlation coefficients. Default: pch = "cross". The caption explaining the insignificance marker is added only for pch = "cross" (or 4).

colors

A character vector of exactly three colors for the gradient: low (negative correlations), mid (zero), and high (positive correlations). Must be a diverging palette so that the sign of the correlation is visually obvious. Default: c("#EA4335", "white", "#4285F4") (red-white-blue).

ggcorrplot.args

A list of additional (mostly aesthetic) arguments passed to ggcorrplot::ggcorrplot(). Do not include the following arguments, which are set internally: corr, p.mat, sig.level, ggtheme, colors, type, lab, pch, legend.title, digits.

subtitle

The text for the plot subtitle.

caption

The text for the plot caption. If the insignificance marker caption is shown (see pch), this text is displayed above it.

type

A character specifying the type of statistical approach:

• "parametric"

• "nonparametric"

• "robust"

• "bayes"

You can specify just the initial letter (e.g. "np" or "bf"). Matching is on the initial lowercase letter only, so any other value (including capitalized values such as "Bayes") falls back to "parametric" without a warning.

digits

Number of digits for rounding or significant figures. May also be "signif" to return significant figures or "scientific" to return scientific notation. Control the number of digits by adding the value as suffix, e.g. digits = "scientific4" to have scientific notation with 4 decimal places, or digits = "signif5" for 5 significant figures (see also signif()).

conf.level

Scalar between 0 and 1 (default: 95% confidence/credible intervals, 0.95).

tr

Trim level for the mean when carrying out robust tests. In case of an error, try reducing the value of tr, which is by default set to 0.2. Lowering the value might help.

bf.prior

A number between 0.5 and 2 (default 0.707), the prior width to use in calculating Bayes factors and posterior estimates. In addition to numeric arguments, several named values are also recognized: "medium", "wide", and "ultrawide", corresponding to r scale values of 1/2, sqrt(2)/2, and 1, respectively. In case of an ANOVA, this value corresponds to scale for fixed effects.

p.adjust.method

Adjustment method for p-values for multiple comparisons. Possible methods are: "holm" (default), "hochberg", "hommel", "bonferroni", "BH", "BY", "fdr", "none".

ggplot.component

A {ggplot2} component, or a list of components, to add to the plot (Default: NULL). This is mostly helpful for the grouped_ variants, where it is applied to each individual plot.

ggtheme

A {ggplot2} theme (Default: theme_ggstatsplot()). Any {ggplot2} theme (e.g., ggplot2::theme_bw()) or theme from an extension package (e.g., ggthemes::theme_fivethirtyeight()) can be used. Note that some themes remove plot details. For example, ggthemes::theme_fivethirtyeight() removes the secondary Y-axis, which ggbetweenstats() uses to show details about pairwise comparisons.

grouping.var

A single grouping variable. A separate plot is created for each of its levels (in factor level order, or in order of appearance for character variables). Rows with a missing value in this variable are removed.

plotgrid.args

A list of additional arguments passed to patchwork::wrap_plots(), except for guides, which has its own argument.

annotation.args

A list of additional arguments passed to patchwork::plot_annotation().

Value

A patchwork object combining one plot per level of grouping.var (see combine_plots()).

Details

Missing values are handled using pairwise deletion (each correlation uses all complete pairs of observations). If sample sizes then differ across pairs, the legend shows their minimum, mode, and maximum. Partial correlations use only complete cases.

For details, see: https://www.indrapatil.com/ggstatsplot/articles/web_only/ggcorrmat.html

See also

ggcorrmat(), ggscatterstats(), grouped_ggscatterstats()

Examples

set.seed(123)

grouped_ggcorrmat(
  data = iris,
  grouping.var = Species,
  type = "robust",
  colors = c("#0072B2", "white", "#D55E00"),
  plotgrid.args = list(ncol = 1L),
  annotation.args = list(tag_levels = "i")
)
